Aluminum Nitride Ceramic Substrate
Home /Aluminum Nitride Ceramic Substrate /

High thermal conductivity Aluminum Nitride Ceramic Substrate

Aluminum Nitride Ceramic Plate

High thermal conductivity Aluminum Nitride Ceramic Substrate

Our Aluminum Nitride (AlN) materials have high thermal conductivity, high electric insulation and have a coefficient of thermal expansion similar to that of silicon (Si). It is used as a substrate for power module and LED.

Product details:

1.Material:Aluminum Nitride.

2.Function:insulating device ceramic.

3.Type:Ceramic.

4.Color:Gray.

5.Can be customed:yes,please provide drawings for specific products.

High thermal conductivity Aluminum Nitride Ceramic Substrate

Product Description:

Aluminum Nitride (AlN) is the best available thermally conductive material (170 W/mK) that is also a strong electric insulator. It is therefore used in a variety of applications where heat needs to be transferred away from a component or circuit(such as below application picture). Furthermore, it has a low coefficient of thermal expansions resulting in a close CTE match with other materials like silicon and other ceramics. These characteristics make AlN a perfect material for packages and submounts of power components like power LEDs, high powers IC, high voltage inductors,…

Our Aluminum Nitride substrates (AlN) are available in various sizes and thicknesses. Thanks to a large and live inventory, we can ship your part fast for you to start your project.

Our Service:
Please contact us for customization. We can also supply Aluminum Nitride (AlN) Ceramic with thermal conductivity up to 230W/mK

Specification:

Dimension (LxW) 50.8mmx50.8mm/114.3 mm x 114.3 mm etc.
Thickness 0.1-10 mm
Thermal Conductivity 170-230W/m.K
Dielectric Constant 8-9 (MHz)
Bulk Density 3.3 g/cm³
Surface Roughness Ra < 0.6 μm on both sides

Company Advantage:

Huaqing Founded in 2004, with sum investment of 80Million RMB, registered capital 40Million RMB. Huaqing's AlN & Al2O3 ceramic products have high thermal-conductivity, low dielectric constant, good dissipation factor and excellent mechanical property compared with the other factories in the industry. AlN & Al2O3 ceramic are widely used in HBLED, opto-communication, IGBT, power devices, TEC and the other high-end applications.

Workshop & Equipment:









Packaging & Delivery:
Deliver by UPS,DHL,Fedex etc
